Deep groove ball nose end mill
Category: Products
Tool Type: Deep groove ball cutter
Product Description
| Type No. | Diameter | Corner R | Flute length | Effective length | Overall length | Shank Dia | Flutes |
| D | R | Lc | L1 | L | d | F | |
|
NBM2006A |
D2 |
R1 |
2 |
6 |
L50 |
4 |
2 |
|
NBM2008A |
D2 |
R1 |
2 |
8 |
L50 |
4 |
2 |
|
NBM2010A |
D2 |
R1 |
2 |
10 |
L50 |
4 |
2 |
|
NBM2012A |
D2 |
R1 |
2 |
12 |
L50 |
4 |
2 |
|
NBM2016A |
D2 |
R1 |
2 |
16 |
L50 |
4 |
2 |
|
NBM2018A |
D2 |
R1 |
2 |
18 |
L50 |
4 |
2 |
|
NBM2020A |
D2 |
R1 |
2 |
20 |
L50 |
4 |
2 |
|
NBM2008 |
D2 |
R1 |
2 |
8 |
L60 |
6 |
2 |
|
NBM2010 |
D2 |
R1 |
2 |
10 |
L60 |
6 |
2 |
|
NBM2012 |
D2 |
R1 |
2 |
12 |
L60 |
6 |
2 |
|
NBM2016 |
D2 |
R1 |
2 |
16 |
L60 |
6 |
2 |
|
NBM2018 |
D2 |
R1 |
2 |
18 |
L60 |
6 |
2 |
|
NBM2020 |
D2 |
R1 |
2 |
20 |
L60 |
6 |
2 |
|
NBM3008A |
D3 |
R1.5 |
3 |
8 |
L50 |
4 |
2 |
|
NBM3010A |
D3 |
R1.5 |
3 |
10 |
L50 |
4 |
2 |
|
NBM3012A |
D3 |
R1.5 |
3 |
12 |
L50 |
4 |
2 |
|
NBM3016A |
D3 |
R1.5 |
3 |
16 |
L50 |
4 |
2 |
|
NBM3008 |
D3 |
R1.5 |
3 |
8 |
L60 |
6 |
2 |
|
NBM3010 |
D3 |
R1.5 |
3 |
10 |
L60 |
6 |
2 |
|
NBM3012 |
D3 |
R1.5 |
3 |
12 |
L60 |
6 |
2 |
|
NBM3016 |
D3 |
R1.5 |
3 |
16 |
L60 |
6 |
2 |
|
NBM3020 |
D3 |
R1.5 |
3 |
20 |
L60 |
6 |
2 |
|
NBM3020L |
D3 |
R1.5 |
3 |
20 |
L75 |
6 |
2 |
|
NBM3026 |
D3 |
R1.5 |
3 |
26 |
L60 |
6 |
2 |
|
NBM3026L |
D3 |
R1.5 |
3 |
26 |
L75 |
6 |
2 |
|
NBM4010 |
D4 |
R2 |
4 |
10 |
L60 |
6 |
2 |
|
NBM4012 |
D4 |
R2 |
4 |
12 |
L60 |
6 |
2 |
|
NBM4012L |
D4 |
R2 |
4 |
12 |
L75 |
6 |
2 |
|
NBM4016 |
D4 |
R2 |
4 |
16 |
L60 |
6 |
2 |
|
NBM4016L |
D4 |
R2 |
4 |
16 |
L75 |
6 |
2 |
|
NBM4020 |
D4 |
R2 |
4 |
20 |
L60 |
6 |
2 |
|
NBM4020L |
D4 |
R2 |
4 |
20 |
L75 |
6 |
2 |
|
NBM4026 |
D4 |
R2 |
4 |
26 |
L60 |
6 |
2 |
|
NBM4026L |
D4 |
R2 |
4 |
26 |
L75 |
6 |
2 |
| Cast iron,Carbon steel | Alloy steel,Tool steel | Tempered steel Prehardened steel |
Heat-treated steel | Heat-treated steel | Stainless steel | Aluminum alloy | Titanium alloy | Copper alloy |
|
（~22HRC） |
（25~35HRC） |
（35~45HRC） |
（45~55HRC） |
（55~65HRC） |
（~30HRC） |
（~150HB） |
（~32HRC） |
C11000 |
|
S50C/HT250/Q235 |
P20/H13/D2 |
NAK80/718H/FDAC |
SKD61/1.2343ESR |
SKD11/SKH51 |
SUS304/316/316L |
5052/6061/7075 |
Ti-6Al-4V |
B152C11000 |
| ▣ | ▣ | ◉ | ◉ | ◉ | ▣ | -- | -- | ▣ |
◉ 最适合 Most Suitable ▣ 适合 Suitable -- 不适合 Not Suitable
